Scanners

35mm Negative and Slide Scanners
Presented here are some of the scanners one can find by doing basic searches for 35mm negative, slide, and film scanners, through the major internet search engines. Discontinued products are shown because of the availability and quality of these devices and to help make informed comparisons between older units and newer models. Note: Megapixels is used as the total number of pixels in the scanned frame. DPI is used as the measurement for any side of a one inch square – to calculate its megapixel equivalent, multiply by frame size.



Innovative Technologies ITNS-300
Class=5 megapixel

Manual feed

Price=$60

www.ithomeproducts.com/product/digital-office

Manufacturer says: “Features:

* Converts 35mm film negatives and slides to digital images.
* Archive a photo collection in a format that’s more permanent, easier to share, and fully digital for increased creative control.
* Easy-to-use scanner with 5.0 Mega-Pixel image sensor.
* Automatically aligns each slide and negative.
* Adjusts to the proper focus, exposure, and color for crisp, clear digital images of all your originals.
* Includes USB cable and PC software for editing, cropping, and resizing.

RX OPTICS Slide 2 PC

Class=5 megapixel

Manual feed

Price Range = $50

Manufacturer home page not readily available – product sold through third parties only. No easily obtainable on line specifications or access to directly contact company.

Manufacturer says: “Converts your 35MM Slides & Film Negatives into Digital Images. Clear, bright digital images with amazing quality. Captures high resolution digital images to your PC. Preserve and protect cherished memories in seconds. Stores Images in 5 Mega Pixel size. Crop, edit and resize slides like a professional.

Includes:
USB Cable
Software CD for Windows XP and Vista

System requirements:

To ensure the best results your computer must have the following minimum hardware:
*IBM PC Compatible
*Intel Pentium III CPU or higher
*128MB RAM
*3D display card with 64MB RAM or higher that supports 32 bit color
*At least one 1.1 USB port available
*Windows XP (with service pack 2 or higher) or Windows Vista Home or Professional edition
*40 GB or higher hard drive

Made in China

SVP FilmScan FS-1000bk

Class=5 megapixel

Manual feed

Price Range: $50 to $110

Manufacturer product page: http://www.svpcam.com/FilmScanner_FS1000_p/filmscanner-fs1000.htm

Manufacturer says: “Specification
Image Sensor

1/2.5″ inch 5 mega CMOS sensor (5.17 Mega pixels)
Lens: F no.= 6.0, 4 Glass elements, Half-field Angle=15
Focus Range: Fixed focus
Exposure Control: Automatic
Color Balance: Automatic
Scan Quality 5MP ( 3,600 dpi) plus enhanched mode
Data Conversion 10 bits per color channel
Scan Method Single pass
Light Source White LED Back light
Interface: USB 2.0
Power: USB port
Dimensions 87x87x164mm
Weight 0.58kg
Operating Systems Windows XP/Vista
Package Content Film scanner with connection cable, 35mm Negative Film Holder, Positive Slide Holder, Brush, User Manual, CD ROM Installer”

SVP FilmScanSS-400

Class=5 megapixel

Manual feed

Price Range: They only offer two of their latest scanners for direct purchase but many models of their units are available through third parties and range from $50 to $110.

Manufacturer home page is available – Silicon Valley Peripherals.

Manufacturer says: “SPECIFICATIONS
Image Sensor

Scan color or monochrome film and mounted slides
Lens

F no.= 2.0, 4 Glass elements,

Focus Range
Fixed focus
Exposure Control
Automatic
Color Balance Automatic
Scan Quality 1,800 dpi /3,600 dpi(SW interpolation)
Data Conversion 10 bits per color channel
Scan Method

Single pass
Light Source Back light (3 white LEDs)
Interface USB 2.0
Power

USB port

Dimensions 82x86x152mm
Weight 0.58kg
Operating Systems Windows XP/Vista”

SVP FilmScan FS-1000

Class=5 megapixel

Manual feed

Price Range: They only offer two of their latest scanners for direct purchase but many models of their units are available through third parties and range from $50 to $110.

Manufacturer home page is available – Silicon Valley Peripherals.

Manufacturer says: “SPECIFICATIONS
Sensor

1/2.5″ inch 5 mega CMOS sensor (5.17 Mega pixels)
Lens

F no.= 6.0, 4 Glass elements, Half-field Angle=15

Focus Range
Fixed focus
Exposure Control
Automatic
Color Balance Automatic
Scan Quality 5MP ( 3,600 dpi) plus enhanched mode
Data Conversion 10 bits per color channel
Scan Method

Single pass
Light Source White LED Back light
Interface USB 2.0
Power

USB port

Dimensions 87x87x164mm
Weight 0.58kg
Self timer 2/10/10+2 seconds
Operating Systems Windows XP/Vista

Package Content
Film scanner with connection cable, 35mm Negative Film Holder, Positive Slide Holder, Brush, User Manual, CD ROM Installer”

SVP FS-1700-Blue, Silver & Black

Class=5 megapixel
Manual feed
Price Range: $80-$90

Manufacturer product page: http://www.svp-tech.com/fs1700bl/fs1700bl.htm

Manufacturer says: “SPECIFICATIONS Sensor 5.1 mega pixels CMOS sensor Lens F/3.6 f=4.83 LCD 2.4” inch LTPS LCD Display Internal memory 32MB External Storage Media SD/MMC card Focus Range Fixed focus Exposure Control Automatic Color Balance Automatic Scan high resolution 3,600 dpi interpolation resolution Data Conversion 12 bits per color channel Scan Method Single pass Light Source Back light (3 white LEDs) Interface USB 2.0, TV-out (video 3.5mm jack) USB Configuration Mass Storage Device Class/MSDC Power 5V adapter, or USB power, or 4XAAA Alkaline Batteries (batteries not included) Dimensions 86.5×87.5×104.5mm Weight 300g”

SVP FS-1800

Class=5 megapixel
Manual feed
Price Range: $100 Discontinued
Manufacturer product page: http://www.svp-tech.com

Review says: “NEW! SVP Digital Film 35mm Negative & Slides Scanner with Flip LCD + AV Out! (SVP 32GB SDHC Memory Card Included) Overview

SVP FS-1800 Digital Film Scanner is a innovative standalone film scanner that instantly converts 35mm film negatives and slides into digital images without the need for a computer or application software. Now you can preserve all their photo memories by turning the millions of photographs now stored on slides and negatives into digital images to preserve them forever. We have created a very simple-to-use device that works right out of the box and produces a five-megapixel digital image in five seconds at a push of a button. The device features a 5mpix scanning chip (i.e. 2592×1680 pixels, 3600 dpi) producing the images large enough to be printed on a A4 page! Unlike similar devices currently on the market, the SVP FS-1800 Digital Film Scanner does not require a computer or learning a new software program, and it takes very little space to operate, store or transport.The SVP FS-1800 Digital Film Scanner is uniquely designed with a built-in flip 2.4-inch color LCD screen for viewing and editing, and a memory card reader that saves the converted images directly onto SD memory cards. Within seconds, users can view their scanned photos through a digital picture frame or upload to a computer. It’s designed to be used right out of the box by simply plugging it into an AC outlet.”

SVP FS-35-I

Class=5 megapixel
Manual feed
Price Range: $80 where available. Discontinued
Manufacturer product page: http://www.svp-tech.com

Manufacturer says: “nothing”

SVP FS-35-II

Class=5 megapixel
Manual feed
Price Range: $100 where available. Discontinued
Manufacturer product page: http://www.svp-tech.com

Manufacturer says: “nothing”

SVP FS-1200-B

Class=5 megapixel

Manual feed

Price Range
Manufacturer product page: http://www.svpcam.com/ProductDetails.asp?ProductCode=FILMSCANNER-FS1200

Manufacturer says:
Features

* 35mm Film Strip & Mounted Slide
48 Bit 3600 dpi optical resolution
Scan color or monochrome film and mounted slides
One button scanning
One of the fastest scanner available
Hi Speed scan and preview (0.5 sec)”

SVP PS9000
Class=5 megapixel
Manual feed
Price Range: $150 Discontinued but available
Manufacturer product page: http://www.svp-tech.com
Manufacturer says:
SVP PS9000 3-in-1 Photo Scanner

o Convert your print photo slides and negative film to 5MP digital images
o Scanner works with the touch of a button
o Photo negatives or slides scan in less than a second
o Downloadable into a digital file to print, copy to CD or store
o Free user application, which allows you easily check about how the final output
o Image correction settings (brightness, contrast, saturation, hue), crop and resize your slides as well as convert your negatives into positives
o 5.1MP CMOS sensor
o Features a 5.1-megapixel scanning chip
o Connects to USB-enabled PC for data transfer and power
o No warm-up, calibration or scan head pass needed
o Ideal for safeguarding images from weddings, holidays and treasured family moments
o Windows XP, Vista Compatible (requires USB 2.0)
Includes:
o SVP PS9000 photo scanner
o Negative/slide film cartridge
o Roll film cartridge
o Three print photo (3×5: 3R, 4×6: 4R, 5×7: 5R) cartridges
o USB cable
o User manual
o CD Rom with Driver and image editing software

SVP FS-9700-B
Class=5 megapixel
Manual feed
Price Range: $170
Manufacturer product page: http://www.svp-tech.com
Manufacturer says nothingn but other sources say: “Technical Details

* Converts all 35mm color/monochrome negatives and mounted slides to digital at the touch of a button, requires less than 1 seconds to convert an image
* 5 Mega Pixel Standalone Film Scanner — no computer or software required to operate
* Built-in 2.4-inch color LCD screen to view and edit images, USB Power from Adapter
* Supporting Preview, Playback, and Editing Function, Auto Exposure/Color Balance Algorism by Powerful Processor
* Saves images directly on SD/MMC memory cards, and with TV out feature

› See more technical details
Product Details

* Shipping Weight: 3 pounds”

Ion Scan2PC

Class=5 megapixel

Manual feed

Price Range: $60-$100

The two scanners pictured here are essentially the same except for one has an SD RAM slot and can write its images directly to these.

Manufacturer says: “”

Ion Scan2PC

Class=5 megapixel

Manual feed

Price Range: $60-$100

This model features view screen and SD RAM slot.

Manufacturer says: “”

Film2PC

Class=5 megapixel

Manual feed

Price Range: $100

Manufacturer home page www.ithomeproducts.com

Manufacturer says: “Scanner weighs in at 48 bit. www.ionaudio.com. ArcSoft Media Impression software bundled with scanner. Manufactuer has good descriptions of products.


Innovative Technologies ITNS-300

Class=5 megapixel

Manual feed

Price Range $75

Manufacturer home page www.ithomeproducts.com

Manufacturer says: “”

Innovative Technologies ITNS-301

Class=5 megapixel

Manual feed

Price Range: $50

Manufacturer product page http://www.ithomeproducts.com/product/35mm-negative-film-slide-scanner-built-monitor

Manufacturer says: “Features:

* Stand-alone unit with 2.4″ LCD Screen and “Direct Scan to Flash Drive” allows for operation without a PC.
* Converts 35mm film negatives and slides to digital images.
* Archive a photo collection in a format that’s more permanent, easier to share, and fully digital for increased creative control.
* Easy-to-use scanner with 5.0 Mega-Pixel image sensor.
* Automatically aligns each slide and negative.
* Adjusts the focus, exposure, and color for crisp, clear digital copies of all your originals.

Innovative Technologies ITNS-400

Class=5 megapixel

Manual

Price Range

Manufacturer home page www.ithomeproducts.com

Manufacturer says: “”

Innovative Technologies ITNS-401

Class=5 megapixel
Manual feed

Price Range

Manufacturer home page www.ithomeproducts.com

Manufacturer says: “”

Innovative Technologies ITNS-500

Class=5 megapixel
Multi scanner – Manual feed

Price Range

Manufacturer home page www.ithomeproducts.com

Manufacturer says: “”

Kjb Digifilmscan Fs-C1

Class=5 megapixel

Manufacturer says “5MP CMOS sensor with 10 bits per color channel 1 829 DPI scanning maximum available” – Not at 5megapixel.

Manual feed
Price Range = $150 – Currently unavailable

Manufacturer home page not available

Notice similarity between this scanner and several other, less expensive units.

ScanPro – SPFS1000

Class=5 megapixel

Manual feed

Price Range $75

Manufacturer home page if available

Manufacturer says: “”The manufactuer’s math as stated in their ad is at least vague – “device features a 5mpix scanning chip (i.e. 2592×1680 pixels, 3600 dpi) producing the images large enough to be printed on a A4 page!”. 5mpx can be 2592×1680 but 3600dpi=30 megapixels. Who uses A4?

Jobar JB5184

Class=5 megapixel

Manual feed

Price Range – $50

Manufacturer home page: www.jobar.com

Manufacturer says: “”

Veho VFS-004 Negative & Film Scanner

Class=5 megapixel

Manual feed

Price Range – $75

Manufacturer’s scanner page: http://www.veho-uk.com/product.aspx?id=34

Manufacturer says: “”

Veho VFS-008

Class=5 megapixel

Manual feed

Price Range

Manufacturer’s scanner page: http://www.veho-uk.com

Manufacturer says: “”

Veho VFS-002M Colourbright

Class=5 megapixel

Manual feed

Price Range – $75

Manufacturer’s scanner page: http://www.veho-uk.com/product.aspx?id=34. Scans 110 film

Manufacturer says: “”

Veho VSF-008

Class=5 megapixel

Manual feed

Price Range

Manufacturer’s scanner page: http://www.veho-uk.com/product.aspx?id=34 Battery operated, writes to SD, scans 110 film

Manufacturer says: “”


Wolverine F2D200

Class=5 megapixel

Manual feed

Price Range – $125

Manufacturer home page: www.wolverinedata.com

Manufactuer says “Built-in 2.4″ Color TFT LCD screen Built-in SD/SDHC Memory Card Slot Video-out to TV Connection 25MB internal memory (holds 25 images) Image Sensor: 1/1.8” inch 5 mega pixel CMOS sensor Lens: F no.= 2.0, 4 Glass elements Focus Range: Fixed focus Exposure Control: Automatic Color Balance: Automatic Scan Quality: 1,800 dpi Image Width: 2520 pixels Image Height: 1680 pixels Image Horizontal Resolution: 96 dpi Image Vertical Resolution: 96 dpi Bit Depth: 24 Color Representation: sRGB Scan Method: Single pass Light Source: Back light (3 white LEDs) Interface: USB 2.0 Power: 5V adapter, or USB power Size: 6(H) x 3(W) x 3(D) inches Weight: 14 ounces

Compare Image Size with dpi, then cross reference with resolution – This is a 5 megapixel class scanner.

Wolverine F2D100

Class=5 megapixel

Manual feed

Manufacturer home page: www.wolverinedata.com

Price Range – $100

Manufacturer says: “”

VuPoint FC-C520-VP-BX2

Class=5 megapixel

Manual feed

Price Range

Manufacturer home page: http://www.vupointsolutions.com

Manufacturer says: “”

Slide Scanner Negative Converter

Class=5 megapixel

Manual feed

Price Range=$100

Manufacturer home not available. Sold by www.improvementscatalog.com

Manufacturer says: “* Slide Scanner Negative Converter scans color or monochrome 35mm and 110mm film and 135mm mounted slides * 48 bits, 3600 dpi optical interpolated resolution * Automatic color balance and exposure control * Great gift for Father’s Day. birthday or anniversary * Slide Scanner Negative Converter is Windows® XP, Vista (32 bits/64 bits) and Mac OSX compatible”

VuPoint FC-C521S1-VP

Class=5 megapixel

Manual feed

Price Range

Manufacturer home page: www.vupointsolutions.com

Manufacturer says: “Image Sensor 5.0 Mega pixels CMOS sensor Lens F no.= 3.0, 4 Glass elements View Angle 54° Panel 2.4” TFT LCD Focus Range Fixed focus Exposure Control Automatic, manual (-2.0EV ~ + 2.0EV) Color Balance Automatic Scan High Resolution 2592 x 1680 (film) Data Conversion 10 bits per color channel Film Type 35mm Negative, Monochrome, Slide Scan Method Single pass Button Left, Right, Start Light Source Back light (3 white LED) TV Out NTSC; PAL Internal Memory Built-in 32 NAND flash External Memory SD card slot Interface USB 1.1; Mass storage device Power Adapter DC 5V (adapter included) Software Compatibility Arcsoft Photo Impression 6: Windows® XP, Windows® Vista™, Windows® 7 System Requirements Windows ® 98SE (driver installation needed), Windows® 2000, Windows® ME, Windows® XP, Windows® Vista (32-bit/64-bit), Mac OS® 10.4

VuPoint FS-C1-VPl

Class=5 megapixel

Manual feed

Price Range – $50

Manufacturer home page: http://www.vupointsolutions.com

Manufacturer says: “The film scanner has a 4-element glass lens, a 5 megapixel CMOS CCD and can scan and preview an image in just 5 seconds.”

VuPoint FC-C501-VP

Class=5 megapixel

Manual feed

Price Range –

Manufacturer says: “Image Sensor 5.0 Mega pixels CMOS sensor Lens F no.= 3.0, 4 Glass elements View Angle 54° Panel 2.4 TFT LCD Focus Range Fixed focus Exposure Control Automatic, manual (-2.0EV ~ + 2.0EV) Color Balance Automatic Scan High Resolution 2592 x 1680 Data Conversion 10 bits per color channel Film Type 35mm Negative, Monochrome, Slide Photo Size 3” x 5”, 4” x 6”, 5” x 7” Scan Method Single pass Button Left, Right, Start Light Source Back light (3 white LED) TV Out NTSC; PAL Internal Memory Built-in 32 NAND flash External Memory SD card slot Interface USB 1.1; Mass storage device Power Adapter DC 5V (adapter included) Software Compatibility Arcsoft Photo Impression 6: Windows® XP and Windows® Vista™ (32-bit/64-bit) System Requirements Windows ® 98SE (driver installation needed), Windows® 2000, Windows® ME, Windows® XP, Windows® Vista (32-bit/64-bit), Mac OS® 10.4 or above (driver free/mass storage)”

Manufacturer home page: www.vupointsolutions.com

Pacific Image Memor-ease, 35mm Film Scanner

Class=5 megapixel

Manual feed

Price Range $80

Manufacturer home page: www.scanace.com

Manufacturer says: “”
Technical support at this company is a joke. Here is a comment from a customer who tried to get help: “In deference to tech support, I can’t find them with a geiger counter. I have been calling it for 3 days, the line has always been busy during various regular hour calls,

Pandigital PANSCN03 4-Inch X 6-Inch Slide/Negative Scanner

Class=5 megapixel

Manual feed

Price Range: $80

Manufacturer home page unavailable

Manufacturer says: “”

iConvert Slide and Negative Digital Scanner

Class=5 megapixel

Manual feed

Price Range: $60-90

Manufacturer home page: www.brookstone.com

Manufacturer says: “iConvert® captures the images as high-resolution (600, 1200, 1800 or 3600 dpi) digital files you can save, edit and share. Compatible with Windows® 98/XP/Vista®, Mac® OS X 10.4 and later (with Intel® processor).”

Imagelab FS5CO5 5 Megapixel Slide and Negative Scanner

Class=5 megapixel

Manual feed

Price Range: $60-$80

Manufacturer product page: http://www.imagelab.us/fs5c05scanner.html

Manufacturer says: “Specifications:

*
Image Sensor: 5 Megapixel CMOS sensor
*
Scan High Resolution: 3600 dpi
*
Scan Method: Single pass
*
Computer Interface: USB 1.1
*
Computer Compatibility: Windows ME/2000/XP/Vista
MAC OSX 10.2 or higher
*
Dimensions: 7 x 4.15 x 3
*
Weight: 0.95 lbs
*
Power Source: AC Power or Battery (3 AAA)”

Epson FilmScan 200 Film Scanner

Class=1200 dpi

Manual feed

Price Range: $25 if available

Manufacturer home page is Epson America but scanner is ancient, out of production, and unsupported.

SCSI interface.

Smart Digital Image Copier Color/Monochrome Film 135mm Slide Scanner

Class=5 megapixel

Manual feed

Price Range: Unavailable

Manufacturer home page not available
Manufacturer says: ” * Handles B&W and color film, include slide/135/110 film * High-end 1/4 CMOS image sensor with 48-bit 3600 optical resolution * Automatic exposure control and color balance * Include easy image transfer software * Compatible with Windows XP, Vista, Windows 7 Pro and Ultimate, (32 bits/64 bits) and Mac OSX

SmartDisk SmartScan 3600
Class=3600dpi
Motor driven
Price Range-$200
Manufacturer home page:
Manufacturer says: "SmartDisk’s SmartScan 3600 is ideal for graphic designers, professional photographers and photo enthusiasts. It scans 35mm negative film rolls or filmstrips and mounted slides. No film holders or templates are required for fast and efficient scanning.The SmartScan 3600 features true optical 3600 dots per inch (dpi) – equivalent to 17.2 million pixels – giving you the quality resolution you need for all of your projects, even image enlargements. With a 3.6 dynamic range, the SmartScan 3600 produces sharp, high-quality scans with accurate color reproduction.The SmartScan 3600 conveniently, quickly and automatically digitizes multiple images and save them to your hard drive at screen resolution. It’s a real time-saver for all of your web design and multimedia projects. The superior clarity of 35mm film, combined with the 3, 600 dpi resolution of the SmartDisk SmartScan 3600, gives you image quality that will satisfy the requirements of even your most demanding graphics work. Great for all of your projects: brochures, newsletters, company profiles, packaging and more. Turn all of your negative film rolls or film strips and slides into digital files that can be burned onto CD or DVD for safe and efficient storage.The SmartDisk SmartScan 3600 works with both PC and Mac systems, featuring fast data transfer and connectivity through either USB or IEEE 1394 interface ports. Simple installation and operating procedures mean you’ll be scanning in a snap. The SmartScan 3600 features batch scanning and auto film loading to save you time and prevent frustration. Its autofocus feature makes it easy to get the best possible images from your film by automatically optimizing each scan."
Canon FS-4000
Class=4000dpi
Motor Driven
Price Range—–Discontinued product
Manufacturer product page: http://www.usa.canon.com/consumer/controller?act=ModelInfoAct&tabact=DownloadDetailTabAct&fcategoryid=351&modelid=7460#ModelDetailAct
Manufacturer says: ” Scanner Specifications Scanner Type Desktop Film Scanner Scanner Element Charged-Coupled Device 3-line color image sensor Light Source Cold cathode mercury fluorescent lamp Max. Resolutions Optical: 4,000dpi (Positives, at 500dpi/1000dpi/200dpi/4000dpi)*: 35mm: 6/12/24/48 seconds ; Advanced Photo System (IX240): 4/9/18/36 seconds Scanning Mode 14-bit scanning for each color (RGB)/16-bit**, 8-bit output 3.4 in 24-bit mode; 4.2 in 42-bit mode Max. Film Size 35mm: Color (Positives/Negatives), Monochrome (Positives/Negatives), Mounted slide film***, Filmstrip ****; Advanced Photo System (IX240): Color (Positives/Negatives), Monochrome (Negatives), Mounted slide film, Cartridge ***** 35mm: 3,780 X 5,669 pixels; Advanced Photo System (IX240): 2,457 X 4,315 pixels 35mm: 24.0 x 36.0 mm; Advanced Photo System (IX240): 15.6 x 27.4 mm Interface USB1.1/SCSI-2; Connectors: USB connector x 1slot/SCSI half-pitch 50-pin (Use interface switch on bottom panel.) Dimensions (W x D x H) 92 x 144 x 368 mm (3.6 x 5.7 x 14.5 inches) Weight 2,400g (5.3lb.)”
Minolta Dimage Dual III
Class=3000dpi
Motor Driven
Price Range: <$200 if available – Model replaced by Dual
Manufacturer’s page: http://ca.konicaminolta.com/products/consumer/digital_camera/dimage/dimagescan-dual3/index.html
Manufacturer says: “ Film type* 35mm film Advanced Photo System film (with the optional APS Adapter) * Film: color / B & W, negative / positive available Optical resolution 2,820 dpi Scan size & input pixels (max.) 35mm film: 24.21 x 36.32 mm, 2,688 x 4,032 pixels Advanced Photo System film: 17.29 x 29.98 mm, 1,920 x 3,328 pixels Scan method Fixed -film, single-pass scan Sensor 3-line CCD, 2,700 pixels / line, primary color filter Multi-sample scanning 2X, 4X, 8X, Off Continuous scan 35mm Film Holder: Max. 6 frames Slide Mount Holder: Max. 4 frames A/D conversion 16 bits Output data 8 bits / 16 bits (per color channel) Dynamic range 4.8 (computed) Scan time (approx.) (AF off, at 2,820 dpi with positive film) (Scan time will be longer with negative film) Windows (USB 2.0) Macintosh (USB 1.1) Pre-scan Final scan Pre-scan Final scan 35mm Film 5 seconds 30 seconds 6 seconds 48 seconds APS Film 6 seconds 27 seconds 7 seconds 32 seconds Light source 3-wave cold-cathode fluorescent lamp Focus Autofocus (Point AF available) & Manual focus Interface USB 2.0 (USB 1.1 compatible) Additional feature Auto Dust Brush, Pixel Polish Power requirements North America, Taiwan and Japan: 100 – 120 Volts AC, 50 / 60 Hz Continental Europe, Oceania, and Asia (except for Taiwan, Japan and Hong Kong): 200 – 240 Volts AC, 50 / 60 Hz England and Hong Kong: 200 – 240 Volts AC, 50 Hz Power Consumption Max. 30 W Dimensions (WxHxD) 145 x 100 x 320 mm / 5.7 x 3.9 x 12.6 inch Weight Approx. 1.5 kg / 52.9 ounce ”

Minolta Dimage Scan Elite 5400 II

Class=5400dpi

Motor Driven

Price Range: $200 (Discontinued but available)

Manufacturer product page: http://ca.konicaminolta.com/products/consumer/digital_camera/dimage/dimagescan-elite5400-2/index.html

Manufacturer says: “Specifications

as of February 20, 2005
Film type 35mm film (color / black & white, negative / positive)
Image sensor 3-line color CCD, 5340 pixels per line, primary-color filter
Scan method Moving film, fixed sensor, single-pass scan
Optical resolution 5400 dpi
Scan size (max.) 25.06 x 37.25 mm (35mm Film Holder scan area: 24 x 36 mm)
No. of pixel input (max.) 5328 x 7920 pixels
A/D conversion 16 bit per color channel
Output 8 bit and 16 bit per color channel
Dynamic range 4.8 (computed value)
Light source White LED
Focus Autofocus and Manual focus (motor drive / manual), Center / Spot focus area
Interface USB 2.0 (USB 1.1 compatible)
Power requirements North America, Taiwan and Japan: 100—120 Volts AC, 50 / 60 Hz
Continental Europe, Oceania, Asia (except Taiwan, Japan, Hong Kong and China): 200—240 Volts AC, 50 / 60 Hz
UK, Hong Kong and China: 200—240 Volts AC, 50 Hz
Power consumption Max. 20 W
Dimensions (W x H x D) 70 mm x 165 mm x 345 mm / 2.8 in. x 6.5 in. x 13.6 in.
Weight Approx. 1.5 kg / 3.3 lb.
Standard accessories 35mm Film Holder FH-M20, Slide Mount Holder SH-M20, USB Cable UC-2 USB 2.0 compatible, AC Adapter (AC-U26 for North America, Taiwan and Japan / AC-U27 for Continental Europe and Singapore / AC-U28 for UK and Hong Kong / AC-U29 for China / AC-U30 for Australia), Reset Tool RT-M10, CD-ROM for DiMAGE Scan Elite 5400 II, Adobe Photoshop Elements 2.0
Operating temperature 10 – 35 degrees centigrade
Operating humidity 15 – 85% humidity without condensation

Specifications and accessories are based on the information available, and are subject to change without notice.

For the latest information, Please visit http://konicaminolta.com/dimage

Specification figures are based on Konica Minolta’s standard testing methods.

Scan Time Test Conditions
35mm positive film scanned at 5400 dpi and 8-bit color depth, without cropping, image processing, or color matching, and with Autoexposure, Autofocus, and Multi-sample scanning OFF.
– Negative film takes longer to scan than positive film.
– Scanning time increases when Digital ICE4TM or color matching functions are used.
– Scanning time varies according to image data volume and PC specifications such as CPU clock speed and memory capacity. “

Minolta Dimage Scan Multi

Class=3000dpi

Motor Driven

Price Range: $1500

Manufacturer product page: http://ca.konicaminolta.com/products/consumer/digital_camera/dimage/dimagescan-multi2/index.html

Manufacturer says: ” Handles a wider range of film format: medium format (6×4.5, 6×6, 6×7, 6×8, 6×9), 35mm, Transmission Electron Microscope (TEM), 35mm, microfilm, Advanced Photo System, and more.
Max. 2,820dpi input resolution (even for medium format films).

Digital ROC™ / Digital GEM™ technology
12-bit A/D conversion
Max. 50 slides continuous scanning
Wide 3.6 dynamic range
Fast scanning raises productivity
JOB function simplifies scan-setting
Precise and easy image compensation
Multi Sample Scanning reduces image noise

A wide range of accessories”

Minolta Dimage Scan Elite Il
Class=3000dpi

Motor Driven

Price Range: $600 if available – Discontinued

Manufacturer product page: http://ca.konicaminolta.com/products/consumer/digital_camera/dimage/dimagescan-elite2/index.html

Manufacturer says: “Film type*

35mm film
Advanced Photo System film (with the optional APS Adapter)
* Film: color / black and white, negative / positive available

Optical resolution

2820 dpi

Scan size & input pixels (max.)

35mm film: 24.21 x 36.32mm, 2688 x 4032 pixels
Advanced Photo System film: 17.29 x 29.98mm,
1920 x 3328 pixels

Scan method

Moving-film, fixed-sensor, single-pass scan

Sensor

RGB 3-line CCD, 2700 pixels / line

Multi-sample scanning

2X, 4X, 8X, 16X, Off

Continuous scan

35mm Film Holder: Max. 6 frames
Slide Mount Holder: Max. 4 frames

A/D conversion

16-bit

Output data

8-bits, 16-bit (per color channel)

Dynamic range

4.8 (computed)

Scan time (approx.)

(Digital ICE3 off, 2820 dpi, positive)
(Scan time will be longer with negative film.)

Windows (IEEE1394)

Macintosh (FireWire)

Pre-scan Final scan Index scan
(/ frame) Pre-scan Final scan Index scan
(/ frame)

35mm film

6 seconds

32 seconds

7 seconds

7 seconds

32 seconds

7 seconds

APS film

7 seconds

27 seconds

7 seconds

8 seconds

28 seconds

7 seconds

Light source

Cold-cathode fluorescent tube

Focus

Autofocus (Point AF available) & manual focus

Interface

USB 1.1: USB 4p x 1, IEEE1394: IEEE1394 6p x 1

Power requirements

North America, Taiwan and Japan: 100 – 120 Volts AC, 50 / 60 Hz Europe, Asia (except Taiwan and Japan) and Oceania: 200 – 240 Volts AC, 50 / 60 Hz

Power consumption

Max. 20 W

Dimensions (WxHxD)

145 x 100 x 325 mm / 5.7 x 3.9 x 12.8 inches

Weight

Approx. 1.5 kg / 52.9 ounces”

Minolta Dimage Scan Speed
Class=2820dpi

Motor Driven

Price Range-$250

Manufacturer home page if available

Manufacturer says: “Scanner Type Film Scanner (35 mm)
Interface SCSI-2 (8-bit)
Optical Resolution 2820 dpi
Max. Resolution (Hardware) 2820 x 2820 dpi
Technical Features
Form Factor Desktop
Scan Element Type CCD
Input Type Color
Media
Max. Supported Media Size 24.2 x 36.3 mm
System Requirements
Operating System Microsoft Windows 98 • Apple MacOS X • Apple MacOS 8
Dimensions
Width 3.6 in.
Depth 10.7 in.
Height 6.3 in.
Weight 4.4 lb.”

Minolta Dimage Scan Elite

Class=2820dpi

Motor Driven

Price Range——-

Manufacturer product page: http://ca.konicaminolta.com/products/consumer/digital_camera/dimage/dimagescan-elite/index.html

Manufacturer says:

Usable film type 35 mm film, Advanced Photo System film
Effective scanning area 35 mm: 24.2 x 36.3 mm
Advanced Photo System film: 17.28 x 29.95 mm
Scan system Single-pass
Optical resolution 2,820 dpi
Image sensor RGB 3-line CCD
Scan time*
(Minolta measurement)
35 mm film
Windows Macintosh
Preview approx. 10 seconds approx. 6 seconds
Final Scan (2,820 dpi) approx. 35 seconds approx. 30 seconds
Advanced Photo System film
Windows Macintosh
Index approx. 8 seconds / frame approx. 6 seconds / frame
Preview approx. 10 seconds approx. 6 seconds
Final Scan (2,820 dpi) approx. 25 seconds approx. 25 seconds
* PC speed is not taken into account.
A/D conversion 12 bits
Output Data 8 bits or 16 bits per color channel
Dynamic Range 3.6
Focus Focus free
Light Source Fluorescent lamp
Interface SCSI – II (SCSI Ports: D-Sub 25 pin, Centronics 50)
Power Requirements North America & Canada 100 – 120 /
Europe, Asia, & Oceania 220 – 240 Volts,
AC 50 / 60 Hz
Power Consumption Max. 30 W
Dimensions (WxHxD) 90.5 x 162 x 272 mm (3-9/16 x 6-3/8 x 10-11/16 inch)
Weight 2.0 kg (70-9/16 ounce)
Standard Accessories Driver software: Windows TWAIN 32 / Utility / ICC Profile, Macintosh Adobe Photoshop Plug-in / Utility / ColorSync Profile / ICC Profile
35 mm Film Holder FH-D1,
Slide Mount Holder SH-D1, Power Cord PW-D1, SCSI Cable SC-11(D-sub 25 pin, Centronics 50), Adobe Photoshop LE, CD-ROM for Dimâge Scan Elite
Optional Accessory Advanced Photo System Adapter AD-10

Nikon Super CoolScan 4000 ED
Class=4000dpi

Motor Driven

Price Range: $1000 when available – Discontinued product

Manufacturer home page if available

Manufacturer says: “Specs: Depth
12.4 in.
Width
3.7 in.
Height
6.6 in.
Form Factor
Desktop
Included Accessories
Templates For 35mm Slides • Templates For FilmStrips • 120 Film Holder
Interface
FireWire (IEEE1394)
Release Date
25 April, 2001
Weight
6.62 lb.
Operating System
Microsoft Windows 2000 • Microsoft Windows 98 Second Edition • Microsoft Windows Millennium Edition • Apple MacOS 8
Platform
PC, Mac
Scanner Type
Film Scanner (35 mm)
Light Source
RGB LED
Supported Media Type
Film • Slides
Max. Supported Media Size
25.1 x 38 mm
Input Type
Color
Scan Element Type
CCD
Optical Resolution
4000 dpi
Max. Resolution (Hardware)
4000 x 4000 dpi
Max. Color Depth
16-bit (64K Colors)
Film Scanning Capabilities
35mm Filmstrip • Positive Film • Negative Film • Color Film • Monochrome Film
Optical Density
4.2 Dmax
Focus Control
Auto Focus • Manual”

Nikon LS-2000

Class=2700dpi

Motor Driven

Price Range: $200 if available. Discontinued product

Manufacturer product page: http://imaging.nikon.com/products/imaging/technology/archives/scanner/scoolscan_2000/

Manufacturer says: & Main Features * 12-bit A/D, 2,700 dpi * High-speed scanning * Autofocus * & * Nikon Color Management System * Multi-sample scanning * Hot swappable adapters * Nikon Scan Ver. 2 Driver Software Back to Top LS-2000 Specifications Reading system/Optics Film type 35mm [135]/IX240 film (Advanced Photo System™ film adapter optional) (positive or negative, color or monochrome) Reading resolution 2,592-pixel monochrome linear CCD 2,700 dpi Film adapter MA-20 SLIDE MOUNT ADAPTER SA-20 STRIP FILM ADAPTER (2 to 6 frames) IA-20 IX240 FILM ADAPTER (optional) SF-200 SLIDE FEEDER (optional) Scanning area 24.3 x 36.5mm (2,592 x 3,894 pixels) Effective area 23.3 x 34.7mm (35mm strip) 16.1 x 26.9mm (IX240) Illumination method Condensed and diffused light Light source R, G, B, LED array Color separation RGB line sequential Imaging optics 6 lenses in 4 groups Autofocus Contrast detection by CCD Focusing area selectable Manual focus Manual focusing by software-controlled servo Scanning/Signal processing Image scanning SCCD and optical systems driven Target fixed Single-pass scan Scan time Approx. 20 sec. at 2,700 dpi (typical scan time without data transfer to computer) The typical scan time with data transfer to computer and output time for display without &CleanImage™& (color negative/color positive) is 30 sec. Density range 3.6 Thumbnail scanning 35mm [135] strip film: 2 to 6 frames IX240 film: 15/25/40 frames Batch scanning Available with SA-20 STRIP FILM ADAPTER (up to 6 frames), optional IA-20 IX240 FILM ADAPTER (up to 40 frames) and optional SF-200 SLIDE FEEDER (up to 50 slides in 1.5mm-thick mounts) A/D conversion 12 bits Output data 8 bits, 12 bits per color channel &CleanImage™& function User selectable (for color films only) Multi-sample scanning User selectable Color Management System Built-in Data transfer Panel indicators READY, BUSY and ERROR status indicated by LED Scanning software Nikon Scan Ver. 2 Interface SCSI-II, SCAM supported SCSI connector D-sub 50 pins half pitch x 2 SCSI ID switch Rotary switch Terminator Built-in active terminator, ON-OFF user selectable Image transfer Single-pass RGB line sequential Maximum transfer rate 4MB/sec. Operating conditions Power requirements 100 – 240VAC, 0.3A – 0.2A, 50/60Hz Environmental Temperature: 10 – 35°C (50 – 95°F) Relative Humidity: 20 – 85% RH (non-condensing) Dimensions (W x D x H) 85.5 x 142 x 275mm (3.4 x 5.6 x 10.8 in.) Weight Approx. 2.4kg (5.3lbs.)&

Nikon Coolscan V ED
Class=4000dpi
Motor Driven
Price Range: $1000
Manufacturer product page: http://www.nikonusa.com/Find-Your-Nikon/Product-Archive/Film-Scanners/9239/COOLSCAN-V-ED.html
Manufacturer says: ” * Tech Specs Key Features * 4000 dpi true optical resolution. * 14-bit A/D converter. * New scanner Nikkor Extra-low Dispersion (ED) glass lens. * Proprietary LED illumination technology. * Fast 38-second scanning. * High-quality CCD sensor. * Direct film loading. * New advanced image processing algorithm for color negative film. * Quick AF and Quick Preview. * All new scan image enhancerAll new scan image enhancer * High-speed USB 2.0 interface. * Digital ICE4 Advanced TM(Digital ICE Quad Advanced). * Media: Negative and positives, in color and monochrome. * 35mm slides: Slides with mounts 1.0-3.2mm thick, 49-50.8mm wide. * 35mm film strips: 2-6 frames; strips of 1-6 frames can be scanned with the optional strip film holder FH-3. * APS (IX240) film: Cartridges of 15, 25 and 40 frames can be scanned with the optional IX240 film adapter IA-20(s). * Slide glass for microscopes: Prepared slides (26x76mm, 0.8-1.5mm thick) can be scanned with optional medical slide holder FH-G1. * Aperture/Scan range (pixels) MA-21: 25.1 x 36.8mm/3,946 x 5,782 pixels/same as slide mount. * SA-21: 25.1 x 38.0mm/3,946 x 5,959 pixels/23.4 x 36.0mm. * IA-20(s): 18.6 x 28.4mm/2,915 x 4,453 pixels/16.1 x 27.4mm. * Scanning system: Fixed film, movable plane single-pass optical scanning system. * Light source: R, G, B and Infrared (IR) LEDs. # Supplied Accessories MA-21 Slide Mounter Adapter, SA-21 Strip Film Adapter”
Nikon Super Coolscan 9000ED
Class=
Motor Driven
Price Range: $2000
Manufacturer product page: http://www.nikonusa.com/Find-Your-Nikon/ProductDetail.page?pid=9237
Manufacturer says: ” * Tech Specs Key Features * Multiple film formats (120/220, 35mm, etc.). * 4000 dpi-true optical resolution. * 16-bit A/D converter. * Large diameter scanner Nikkor Extra-low Dispersion (ED) glass lens. * Improved rod dispersion LED illumination technology. * High-speed scanning (35mm slide film – 40 seconds, 6 x 9 – 185 seconds). * Newly-developed, high-quality 3-line CCD sensor. * New, advanced image processing algorithm for color negative film. * Multi-sample scanning. * Quick AF and Quick Preview. * All NEW! Scan image enhancer. * High-speed IEEE 1394 interface. * Digital ICE4 AdvancedTM (Digital ICE Quad Advanced) with Digital ICE ProfessionalTM – more compatible with Kodachrome film. Tech Specs o Media: Negative and positives, in color and monochrome. o 35mm film: 1-2 strips of 1-6 frames; up to 3 frames of 24 x 48mm or 24 x 65mm panorama film can be scanned with optional 120/220 film rotating holder with glass FH-869GR. o 35mm slides: 1-5 slides with mounts, 1.0-3.2mm thick, 49-50.8mm wide. o Medium-format film: 1-4 frames (6 x 4.5), 1-3 frames (6 x 6), 1-2 frames (6 x 7, 6 x 8 or 6 x 9). o Medium-format slides: Slides with mounts 1.0-3.2mm thick can be scanned with optional 120/220 mounted film holder FH-869M. o 16mm film: 1-3 strips of 1-20 frames can be scanned with optional 16mm film holder FH-816. o Glass slides for microscopes: 1-3 prepared slides (26 x 76mm, 0.8-2mm thick) can be scanned with optional medical slide holder FH-8G1. o Aperture/Scan range (pixels) o FH-835S: 25.4 x 37.5mm/4,000 x 5,904 pixels. o FH-835M: 37.5 x 25.6mm/5,905 x 4,032 pixels. o FH-869S, FH-869G: 6 x 4.5: 56.9 x 42.5mm/8,964 x 6,696 pixels, 6 x 6: 56.9 x 56.9mm/8,964 x 8,964 pixels, 6 x 7: 56.9 x 70.0mm/8,964 x 11,016 pixels, 6 x 8: 56.9 x 77.5mm/8,964 x 12,204 pixels, 6 x 9: 56.9 x 83.7mm/8,964 x 13,176 pixels. o FH-816: 15.0 x 21.48mm/2,362 x 3,384 pixels. o FH-8G1: 46.02 x 24.0mm/7,248 x 3,780 pixels. o Scanning system: Fixed optical, movable media, parallel single-pass scanning system. o Light source: R, G, B and Infrared (IR) LEDs; light source with rod disperser and light output slot. o Image sensor: 10,000-pixel, three-line monochrome linear CCD image sensor. o Color separation: Performed by RGB LEDs. o Optical resolution: Up to 4,000 pixels per inch. o A/D conversion: 16 bits per color. o Density range: 4.8. o Output: Full color or gray scale at 8 or 16 bits per channel. o Focus: Auto and manual; auto focusing point selectable. o Interface: IEEE 1394. o Power requirements: AC 100-240V, 50/60Hz. Operating environment: Temperature 50-95°F (10-35°C), relative humidity 20-60%. o Dimensions: 9.8 x 19.6 x 8.0 in. (W x H x D). o Weight: 19.8 lbs o Scanning time (time to complete preview or scan when no options selected): 13 seconds * Scan: 40 seconds, 120/220 (with FH-869S) Preview: 38 seconds * Scan: 185 seconds “
Nikon Coolscan III (LS-30)

Class=2700dpi

Motor Driven

Price Range: $200-400 Discontinued product

Manufacturer product page: http://imaging.nikon.com/products/imaging/technology/archives/scanner/coolscan_3/index.htm

Manufacturer says: “LS-30 Specifications

Reading system/Optics

Film type

35mm [135]/IX240 film (Advanced Photo System™ film adapter optional)
(positive or negative, color or monochrome)

Reading resolution

2,592-pixel monochrome linear CCD
2,700 dpi

Film adapter

MA-20 SLIDE MOUNT ADAPTER
SA-20 STRIP FILM ADAPTER (2 to 6 frames)
IA-20 IX240 FILM ADAPTER (optional)

Scanning area

24.3 x 36.5mm (2,592 x 3,894 pixels)

Effective area

23.3 x 34.7mm (35mm strip)
16.1 x 26.9mm (IX240)

Illumination method

Condensed and diffused light

Light source

R, G, B, LED array

Color separation

RGB line sequential

Imaging optics

6 lenses in 4 groups

Autofocus

Contrast detection by CCD
Focusing area selectable

Manual focus

Manual focusing by software-controlled servo

Scanning/Signal processing

Image scanning

SCCD and optical systems driven
Target fixed
Single-pass scan

Scan time

Approx. 20 sec. at 2,700 dpi (typical scan time without data transfer to computer)
The typical scan time with data transfer to computer and output time for display without “CleanImage™” (color negative/color positive) is 30 sec.

Density range

3.0

Thumbnail scanning

35mm [135] strip film: 2 to 6 frames
IX240 film: 15/25/40 frames

Batch scanning

Available with SA-20 STRIP FILM ADAPTER (up to 6 frames) and optional IA-20 IX240 FILM ADAPTER (up to 40 frames)

A/D conversion

10 bits

Output data

8 bits per color channel

“CleanImage™” function

User selectable (for color films only)

Color Management System

Built-in

Data transfer

Panel indicators

READY, BUSY and ERROR status indicated by LED

Scanning software

Nikon Scan Ver. 2

Interface

SCSI-II, SCAM supported

SCSI connector
D-sub 50 pins half pitch x 2
SCSI ID switch
Rotary switch
Terminator
Built-in active terminator, ON-OFF user selectable

Image transfer

Single-pass RGB line sequential

Maximum transfer rate

4MB/sec.

Operating conditions

Power requirements

100 – 240VAC, 0.3A – 0.2A, 50/60Hz

Environmental

Temperature: 10 – 35°C (50 – 95°F)
Relative Humidity: 20 – 85% RH (non-condensing)

Dimensions (W x D x H)

85.5 x 142 x 275mm (3.4 x 5.6 x 10.8 in.)

Weight

Approx. 2.4kg (5.3lbs.)

Back to Top

MA-20 SLIDE MOUNT ADAPTER

Mount size

Width: 49 x 50.8mm (1.9 x 2.0 in.)
Thickness: 1.0 x 3.2mm (0.04 x 0.13 in.)

Dimensions (W x H x D)

85.5 x 142 x 275mm (3.4 x 5.6 x 10.8 in.) with LS-30″

Nikon CoolScan IV ED

Class=2900dpi

Motor Driven

Price Range: $300 Discontinued product

Manufacturer product page: http://imaging.nikon.com/products/imaging/technology/archives/scanner/coolscan_4/index.htm

Manufacturer says: “Specifications

Reading system/Optics

Film type

35mm (135)/IX240 film, slide glass for microscope

Reading resolution

2,900 dpi

Film adapters and holders

STRIP FILM ADAPTER SA-21 (2 to 6 frames)
SLIDE MOUNT ADAPTER MA-20(S)
STRIP FILM HOLDER FH-3 (1 to 6 frames)
IX240 FILM ADAPTER IA-20(S) (15/25/40 frames) (optional)
MEDICAL SLIDE HOLDER FH-G1 (for slide glass) (optional)

Scanning area (max.)

25.1 x 38.0mm (2,870 x 4,332 pixels)

Effective area (Size/Pixels)

SA-21
23.3 x 36.0mm (2,657 x 4,104)
MA-20(S)
25.1 x 36.8mm* (2,870 x 4,203)
FH-3
24.0 x 36.0mm (2,736 x 4,104)
IA-20(S)
16.1 x 26.9mm (1,836 x 3,067)
FH-G1
22.9 x 35.0mm (2,610 x 3,989)

Illumination method

R, G, B, and D-LED array

Imaging optics

SCANNER NIKKOR ED lens (7 elements in 4 groups including 3 ED glass elements)

Focusing

Autofocus and Manual focus

Scanning/Signal processing

Scan time

Approx. 42 sec. at 2,900 dpi (35mm), 8-bit output (typical scan time with display, Windows, CMS off)

Density range

3.6

Thumbnail scanning and batch scanning

35mm (135) strip film: 2 to 6 frames
IX240 film cartridge: 15/25/40 frames (optional)

A/D conversion

12 bits

Output data

16 bits, 8 bits per color channel (user selectable)

Digital ICE³™

Digital ICE™, Digital ROC™, Digital GEM™

Color Management System

Built-in

Data transfer

Interface

USB 1.1

Operating conditions

Power requirements

100-240VAC, 0.3-0.2A, 50/60Hz

Environmental conditions

Temperature: 10-35ºC (50-95ºF)
Relative humidity: 20-60% RH (non-condensing)

Dimensions (W x H x D)

93 x 169 x 315mm (3.7 x 6.6 x 12.4 in.)

Weight

Approx. 3kg (6.6 lbs.)

Others**

Accessories included

SLIDE MOUNT ADAPTER MA-20(S),
STRIP FILM ADAPTER SA-21,
STRIP FILM HOLDER FH-3,
USB cable, Nikon Scan 3 Driver Software,
AC power cord, Manual

Bundled software

Photoshop 5.0 LE (Adobe Systems Inc.)”

Nikon Super CoolScan 8000 ED
Class=4000dpi

Motor Driven

Price Range: $1000+ Discontinued product

Manufacturer product page: http://imaging.nikon.com/products/imaging/technology/archives/scanner/scoolscan_8000_ed/index.htm

Manufacturer says: ” Film type Medium (120/220) format Positive and negative, color and monochrome, 6 x 4.5, 6 x 6, 6 x 7, 6 x 8, or 6 x 9 film may be scanned in strips of four (6 x 4.5), three (6 x 6) or two (6 x 7, 6 x 8, 6 x 9) frames, or as 1.0 – 3.2mm mounted slides. 35mm (135) format Positive and negative, color and monochrome. Film maybe scanned in one or two trips of up to six frames each, or as 35mm slides using 1.0 – 3.2mm mounts. Up to three frames of panorama film with frame sizes of 24 x 58mm or 24 x 65mm can also be scanned. 16mm Positive and negative, color and monochrome Electron microscope Positive and negative, color and monochrome, 59 x 82mm Preparates (slide glass for microscope) Prepared slides 26 x 76mm Reading resolution 4,000 dpi (max.) Film adapters and holders 35mm STRIP FILM HOLDER FH-835S 35mm MOUNTED FILM HOLDER FH-835M 120/220 STRIP FILM HOLDER FH-869S 120/220 MOUNTED FILM HOLDER FH-869M (optional) 120/220 STRIP FILM HOLDER WITH GLASS FH-869G (optional) 120/220 FILM ROTATED HOLDER WITH GLASS FH-869GR (optional) 16mm FILM HOLDER FH-816 (optional) MEDICAL SLIDE HOLDER FH-8G1 (optional) Scanning area (max.) 63.5 x 88.0mm (10,000 x 13,860 pixels) Effective area (Size/Pixels) FH-835S 25.4 x 37.5mm (4,000 x 5,904) FH-835M 37.5 x 25.6mm (5,905 x 4,032) (Electron microscope film) 56.9 x 83.7mm (8,964 x 13,176) (24 x 58mm panoramic film) 31.0 x 61.7mm (4,876 x 9,720) (24 x 65mm panoramic film) 31.6 x 68.8mm (4,972 x 10,836) FH-869M (6 x 4.5, 6 x 6) 56.9 x 56.9mm (8,964 x 8,964) (6 x 7, 6 x 8, 6 x 9) 56.9 x 83.7mm (8,964 x 13,176) FH-816 15.0 x 21.5mm (2,362 x 3,384) FH-8G1 46.0 x 24.0mm (7,248 x 3,780) Scanning system Fixed-optical, movable-media parallel single-pass scanning system Light source R, G, B, and D-LED Array Sensor 10,000-pixel, three-line, monochrome linear CCD image sensor Imaging optics SCANNER NIKKOR ED lens (14 elements in 6 groups including 6 ED glass elements) Focus Autofocus and Manual focus Scanning/Signal processing Scanning time 55 sec. at 4,000 dpi (35mm, FH-835M) Approx. 170 sec. at 4,000 dpi (6 x 9, FH-869S) (typical scanning time with display, Windows, 8 bits, CMS on, positive film) Density range 4.2 Thumbnail scanning and batch scanning 35mm strip film: 1 to 12 frames (2 strips) 35mm mount film: 1 to 5 frames 120/220 strip film (6 x 4.5 size): 1 to 4 frames 120/220 mount film: 1 to 2 frames 16mm film: 1 to 60 frames (3 strips) A/D conversion 14 bits Output data 16 bits, 8 bits per color channel (user selectable) Digital ICE³™ Digital ICE™, Digital ROC™, Digital GEM™ Multi-sample scanning 2, 4, 8, 16 times (user selectable) Color Management System Built-in Data transfer Interface IEEE1394 (6-pin) Operating conditions Power requirements 100-240VAC, 0.3-0.2A, 50/60Hz Environmental conditions Temperature: 10-35ºC (50-95ºF) Relative humidity: 20-60% RH (non-condensing) Dimensions (W x H x D) 245 x 485 x 200mm (9.6 x 19.1 x 7.9 in.) Weight Approx. 9kg (19.8 lbs.) Accessories included* 35mm STRIP FILM HOLDER FH-835S, 35mm MOUNTED FILM HOLDER FH-835M, 120/220 STRIP FILM HOLDER FH-869S, IEEE1394 board, IEEE1394 cable (6 pin-6 pin), Nikon Scan 3 Driver Software, AC power cord, Manual

Olympus ES-10
Class=1800dpi
Motor Driven
Price Range: $200 if you can find one
Manufacturer home page: www.olympus.com—The ES-10 is no longer made or supported by Olympus. There were two versions of the scanner-the ES-10P- parallel port and the ES-10S – SCSI.
Pacific Image Prime Film 7250u
Class=7200x3600dpi
Manual feed
Price Range: $150-250
Manufacturer home page: http://www.scanace.com/en/product/pf7250u.php
Manufacturer says:
Optical resolution 7200 x 3600 dpi
16-bit A/D, 16-/8-bit output
Scans slides one at a time
Kodak’s Austin Development Center (KADC) Digital ICE³™ for dust and scratch
removal, color reconstruction, and grain equalization and management.
CyberView X scanning software is capable of scanning a single frame as well as filmstrips. Displaying the preview thumbnails at high speed for final selected frames. CyberView X provides powerful tools for optimizing scanning and color reproduction with adjustable parameters including Image Palette, Color Balance, and Curves and Level setting.

Equipped with USB1.1/2.0 ports, the most popular computer interface
PF7250u offers you the benefit of fast performance.

Bundled with ADOBE PHOTOSHOP® ELEMENTS (WINDOWS/MAC), PF7250u
enables you to edit the images the way you like and helps you organize and share your digitized images with ease.
The new PrimeFilm 7250u Film scanner offers 7200 dpi resolution at an affordable price. This model incorporates KADC – Kodak Austin Developments processing tools:

-Digital ICE™ – Hardware based Dust and Scratch removal with infrared sensors and automatic Software correction.

-DigitalROC™ – Color Restoration; Image color is reconstructed and optimized with Digital ROC Technology

-DigitalGEM™ – Grain Management; minimize grain to restore the image’s sharpness.

Film Type: Negative and positive filmstrips (35mm) or mounted slides
• Opt. Resolution: 7200 x 3600 dpi
(approximate pixel size of a positive image after cropping 9360 x 6528 Pixels)
• Scanning Area: 24.3 x 36.5 mm
• Color Depth: 48 Bit
• Dynamic Range: 3.2 Dmax
• Image Sensor: Linear Color CCD
• LightSource: LED Array
• Interface: USB 2.0/1.1

Recommended System Requirements
Windows:
Pentium 4, Pentium M or Intel Centrino 1.3 GHz
(or Equivalent processor)
Windows XP w/ Service Pack 2 or Windows Vista
1 GB RAM (1.5 or more highly recommended)
10 GB of Available Hard disk space (for software installation
(more required for image storage)
Color Monitor with 16-bit color Video card
1024 x 768 monitor resolution
Microsoft DirectX 9 compatible display driver
DVD Rom drive

Macintosh:
PowerPC G4 or G5 or Multicore Intel Processor
Mac OS 10.4.8
1GB of RAM (1.5 or more highly recommended)
10 GB of Available Hard disk space
(additonal space required for software installation
and more required for image storage)
1024 x 768 monitor resolution
DVD Rom drive
QuickTime 7 software required for multimedia features

REMARKS: Adobe Photoshop Elements is included for editing purposes only
Mac Leopard users will not be able to scan directly into Adobe products.

Scan speeds
ICE OFF
Positive
8 bit 1800 dpi/frame 25 seconds
8 bit 3600 dpi/frame 85 seconds

Negative
8 bit 1800 dpi/frame 30 seconds
8 bit 3600 dpi/frame 90 seconds

ICE ON
Positive
8 bit 1800 dpi/frame 95 seconds
8 bit 3600 dpi/frame 195 seconds

Negative
8 bit 1800 dpi/frame 150 seconds
8 bit 3600 dpi/frame 240 seconds

7200 dpi scan speed data not available at this time

Pacific Image Prime Film 3650u
Class=3600dpi
Manual feed
Price Range: $150-250
Manufacturer home page: www.scanace.com
Manufacturer says: “ Optical resolution 7200 x 3600 dpi 16-bit A/D, 16-/8-bit output Scans slides one at a time Kodak’s Austin Development Center (KADC) Digital ICE³™ for dust and scratch removal, color reconstruction, and grain equalization and management. CyberView X scanning software is capable of scanning a single frame as well as filmstrips. Displaying the preview thumbnails at high speed for final selected frames. CyberView X provides powerful tools for optimizing scanning and color reproduction with adjustable parameters including Image Palette, Color Balance, and Curves and Level setting. Equipped with USB1.1/2.0 ports, the most popular computer interface PF7250u offers you the benefit of fast performance. Bundled with ADOBE PHOTOSHOP® ELEMENTS (WINDOWS/MAC), PF7250u enables you to edit the images the way you like and helps you organize and share your digitized images with ease. The new PrimeFilm 7250u Film scanner offers 7200 dpi resolution at an affordable price. This model incorporates KADC – Kodak Austin Developments processing tools: -Digital ICE™ – Hardware based Dust and Scratch removal with infrared sensors and automatic Software correction. -DigitalROC™ – Color Restoration; Image color is reconstructed and optimized with Digital ROC Technology -DigitalGEM™ – Grain Management; minimize grain to restore the image’s sharpness. Film Type: Negative and positive filmstrips (35mm) or mounted slides · Opt. Resolution: 7200 x 3600 dpi (approximate pixel size of a positive image after cropping 9360 x 6528 Pixels) · Scanning Area: 24.3 x 36.5 mm · Color Depth: 48 Bit · Dynamic Range: 3.2 Dmax · Image Sensor: Linear Color CCD · LightSource: LED Array · Interface: USB 2.0/1.1 Recommended System Requirements Adobe Photoshop Elements is included for editing purposes only Mac Leopard users will not be able to scan directly into Adobe products. Scan speeds ICE OFF Positive 8 bit 1800 dpi/frame 25 seconds 8 bit 3600 dpi/frame 85 seconds Negative 8 bit 1800 dpi/frame 30 seconds 8 bit 3600 dpi/frame 90 seconds ICE ON Positive 8 bit 1800 dpi/frame 95 seconds 8 bit 3600 dpi/frame 195 seconds Negative 8 bit 1800 dpi/frame 150 seconds 8 bit 3600 dpi/frame 240 seconds 7200 dpi scan speed data not available at this time”
Pacific Image Prime Film pf3600
Class=3600dpi
Motor Driven
Price Range: $200 when available – Discontimued
Manufacturer home page: www.scanace.com
Review says: ” This is where a dedicated film scanner would come in extremely handy for those who have rolls of film kept in a box somewhere in the store. In a humid tropical country like Singapore, films do tend to degrade fast and mold would be its greatest enemy. Fortunately, scanner technology has progressed so far and to such a state that it is very affordable and easy to convert any images into a flexible digital format. In addition, scanning and archiving your photos digitally would also mean bettter manageability of your images. Should you need to print or use any of those pictures, they can be easily called up from your PC. The PrimeFilm PF3600 Pro from Pacific Image Electronics is a high-resolution film scanner that’s made to scan films only. With the flexibility to scan 35mm color films, black & white films and slides, the PF3600 Pro is not only a useful tool for the occasional enthusiast who wants to archive their images digitally, it’s also an essential equipment for every professional film photographer. The PrimeFilm PF3600 PRO film scanner. Before we take a more detailed look at the scanner’s features , let’s check out the technical specifications below:- PrimeFilm PF3600 PRO Technical Specifications Scanning Media 35mm slides, filmstrips or roll film Optical Resolution 3600dpi x 3600dpi Max. Scanning Area 24.3mm x 36.5mm # Data Conversion 36 bits per pixel (color mode) # 12 bits per pixel (grayscale mode) Image Sensor Linear array color CCD Scan Method Single pass Light Source Cold cathode fluorescent lamp Scan Time 50 seconds for 35mm slide at 3600dpi 36-bit color scan (file size 102MB/IEEE 1394) Interface USB & IEEE 1394 Dimensions 238mm (L) x 103mm (W) x 177mm (H) Net Weight 2.20kg “
Prime Film 1800u
Class=
Manually Loaded
Price Range: $150
Manufacturer home page: http://www.scanace.com/en/product/1800u.php
Manufacturer says: “High resolution for better images The PrimeFilm 1800 series captures 1800 dots per inch(dpi) giving you 3 times the resolution of the average desktop scanner. For graphics professionals, this means that you can enlarge images to approx. 20 cm x 13 cm (7.8″ x 5.1″) and still maintain the 1:1 300 dpi resolution sufficient for color separation and offset printing. Product Specifications : Scanning Type: 35mm Film Scanner Image Sensor: Linear Array Color CCD Color Mode: 48 bits per pixel Grayscale Mode: 16-bit per pixel Optical Resolution: 1800 dpi (or 4.2 million pixels for a 36 x 24mm image) Maximum Resolution: 1800 x 1800 dpi Light Source: Cold Cathode Fluorescent Lamp Scanning Buffer: 512 K byte Preview Speed: 10 seconds for color Scanning Speed: 35 seconds Max scanning area: 36mm x 24mm Interface: USB 1.1 Power Adapter: Output -12V DC /1A , Input – 100VAC or 240VAC, Frequency: 47Hz to 63Hz Dimensions: 268mm(10.55″) x 166mm, (6.54”) x 66mm(2.60) Weight: 750 grams(1.65 lbs) “
Prime Film pf7250Pro3
Class=
Manually Loaded
Price Range: $500
Manufacturer product page: http://www.scanace.com/en/product/pf7250pro3.php
Manufacturer says:

Optical resolution 7200 x 7200 dpi
16-bit A/D, 16-/8-bit output
Automatically loads and batch scans 35mm roll films and filmstrips
Scans slides one at a time
Auto focus for the sharpest images
Kodak’s Austin Development Center (KADC) Digital ICE³™ for dust and scratch removal,color reconstruction, and grain equalization and management.

What makes the 7250Pro3 an outstanding scanner?
The PF7250 PRO3 operates at 7200 dpi optical resolution, 16-bits per channel with a total output image of 48-bits, which allows users to enlarge images up to 18″ x 12″, 300dpi. With a 3.6 dynamic range, this scanner is designed to produce sharp, high-quality scans with accurate color reproduction.
CyberView X scanning software is capable of scanning a single frame as well as filmstrips. Displaying the preview thumbnails at high speed for final selected frames. CyberView X provides powerful tools for optimizing scanning and color reproduction with adjustable parameters including Image Palette, Color Balance, and Curves and Level setting.

Image Palette
View how an image will be effected on your Image Palette before applying the adjustment. The selected effect image will replace the default thumbnail and allows you to see how the effects look on your image, instantly.

Color Balance
Adjust the brightness, contrast, saturation, and color (CMYK or RGB) of the image, and compare before and after effects in real time.

Curves and Level
Powerful curves and level tools help you to adjust color fidelity to the finest detail based on the image histogram.
Equipped with USB1.1/2.0 ports, the most popular computer interface, PF7250 PRO3 offers you the benefit of fast performance.
Bundled with ADOBE PHOTOSHOP® ELEMENTS (WINDOWS/MAC), PF7250 PRO3 enables you to edit the images the way you like and helps you organize and share your digitized images with ease.
More Surprises?
If your used to unpleasant results of the image quality from high resolution scanning, your worries are over because PF7250 PRO3 now brings in the most powerful digital enhancement technology from Kodak’s Austin Development Center (KADC) Digital ICE³™!
Unlike other application software, the current KADC’s Digital ICE™ technology combined with thePF7250 PRO3 you can perform the dust and scratch removal automatically without doing a lot of time-consuming manual work.

Digital ICE™ uses an extra infrared channel built in PF7250 PRO3, which is in addition to the RGB color channel of the image, to detect the dust or scratches on the surface of film and then repair digitally.

Negatives and prints tend to color-fade with time producing reddish or bluish tint. KADC’s Digital ROC™ will mesmerize you with its capability to automatically restore the color of images that suffer from color-fading or light casting.

Digital ROC™ automatically and meticulously restores the lost color value in faded negative to its original color.

Image noise can be caused by a variety of factors including, high speed film grain, adverse lighting conditions, scanner/digital camera CCD noise, or image enlargement.KADC’s Digital GEM™ allows users to isolate and manage noise/grain in both highlight and shadow areas without sacrificing image detail.

Digital GEM™ analyzes and then remove film grain pattern in negative.

Plustek OpticFilm 7200
Class=7200dp
Manually Loaded
Price Range: $300
Manufacturer home page: www.plustek.com
Manufacturer says: “Interface USB 2.0 Technology Color CCD image sensor Hardware Resolution 7200 x 7200 dpi Dmax 3.3 Max. scanning area 36.8 x 25.4 mm (1.45 “x 1″) * Preview Speed Approx. 10 sec** Scan Speed Approx. 48 sec (3600 dpi)*** Color Depth 48 bit/pixel Illuminated Slide Viewer size 38 x 38 mm Net Weight Approx. 1.35 kg / 2.97 lb (scanner only) Dimensions (D x W x H) 272 x 120 x 119 mm (scanner only) Scan Mode Single Pass Lamp Cold Cathode”
Plustek OpticFilm 7200i
Class=7200dpi
Manually Loaded
Price Range $300-400
Manufacturer home page: www.plustek.com
Manufacturer specs: &Interface USB 2.0 Technology Color CCD image sensor Hardware Resolution 7200 x 7200 dpi Dmax 3.3 Max. scanning area 36.8 x 25.4 mm (1.45 &x 1&) * Preview Speed Approx. 5.6 sec** Scan Speed Approx. 36 sec (3600 dpi), 68 sec (7200 dpi)*** Color Depth 48 bit/pixel Dimensions (D x W x H) 272 x 120 x 119 mm (scanner only) Net Weight Approx. 1.5 kg / 3.1 lb (scanner only) Scan Mode Single Pass Lamp Cold Cathode Film Holder Mounted slides, up to 4 slides Filmstrip, up to 6 frames&
Plustek OpticFilm 7500i SE
Class=7200dpi
Manually Loaded
Price Range $300-350
Manufacturer home page: www.plustek.com
Manufacturer says: “High resolution film scanner with Multi-Exposure, enhanced Multi-Sampling for more quality images… plus iSRD feature for dust and scratch removal ! The Plustek OpticFilm 7500i, a dedicated 7200 dpi film scanner, now brings you a more powerful scanning device with its added Multi-Exposure for slides and negative films which brings out the best quality on photos and images at the most affordable price.
Interface USB 2.0 Technology Color CCD image sensor Hardware Resolution 7200 x 7200 dpi Dynamic Range 3.5 Max. scanning area 36.8 x 25.4 mm (1.45 “x 1″) for negative film Preview Speed 11 sec (positive film), 11.38 sec (negative film) without calibration Scan Speed Approx.73 sec (3600 dpi), 332 sec (7200 dpi) for color slide Hardware Multi-Exposure on negative film Yes Multi-Sampling Yes Infrared Function Yes Color Depth 48 bit/pixel Scan Mode Single Pass Lamp Cold Cathode Dimensions (D x W x H) 272 x 120 x 119 mm / 4.73″x10.7″x4.7” (scanner only) Net Weight Approx. 1.6Kg / 3.5 lbs (scanner only) Film Holder Mounted slides, up to 4 slides Filmstrip, up to 6 frames Infrared BUILT-IN
Plustek OpticFilm 7400
Class=7200dpi
Manually Loaded
Price Range $150-200 Sold through UK sources only.
Manufacturer home page: www.plustek.com
Manufacturer says: “The Plustek OpticFilm 7400 is a dedicated 7200 dpi film scanner, which makes your scanning easier and more efficient. With Plustek’s Multi-Sampling, the noises are eliminated efficiently, and the unique light source gives images more vivid effect and precise color rendering.” “Interface USB 2.0 Technology Color CCD image sensor Hardware Resolution 7200 x 7200 dpi Dynamic Range 3.5 Max. scanning area 36.8 x 25.4 mm (1.45 “x 1″) for negative film Preview Speed Approx 7.57 sec (Multi-Sampling ON) for slide & Approx. 7.96 sec (Multi-Sampling ON) for negative film *without calibration time Scan Speed 3600dpi: Approx. 54.56 sec (Multi-Sampling ON) 7200dpi: Approx. 112.59 sec (Multi-Sampling ON) *under 24bit true color Hardware Multi-Exposure on negative film Yes Multi-Sampling Yes Color Depth 48 bit/pixel Scan Mode Single Pass Lamp White LED Dimensions (D x W x H) 272 x 120 x 119 mm / 4.73″x10.7″x4.7” (scanner only) Net Weight Approx. 1.6Kg / 3.5 lbs (scanner only) Film Holder Mounted slides, up to 4 slides Filmstrip, up to 6 frames.” A review states: “For this film scanner, the producer declares a sensational optical resolution of 7200 dpi. In case of a 35mm-slide or a 35mm-negative, an image file of 70 megapixels is generated in the highest resolution.
Plustek OpticFilm 7500i SE
Class=7200dpi
Manually Loaded
Price Range $300-400
Manufacturer home page: www.plustek.com
Manufacturer says: “Interface USB 2.0 Technology Color CCD image sensor Hardware Resolution 7200 x 7200 dpi Dynamic Range 3.5 Max. scanning area 36.8 x 25.4 mm (1.45 “x 1″) for negative film Preview Speed 11 sec (positive film), 11.38 sec (negative film) without calibration Scan Speed Approx.73 sec (3600 dpi), 332 sec (7200 dpi) for color slide Hardware Multi-Exposure on negative film Yes Multi-Sampling Yes Infrared Function Yes Color Depth 48 bit/pixel Scan Mode Single Pass Lamp Cold Cathode Dimensions (D x W x H) 272 x 120 x 119 mm / 4.73″x10.7″x4.7” (scanner only) Net Weight Approx. 1.6Kg / 3.5 lbs (scanner only) Film Holder Mounted slides, up to 4 slides Filmstrip, up to 6 frames Infrared BUILT-IN
Plustek SmartPhoto F-50
Class=5 megapixel
Manual feed
Price Range $40-60 UK only
Manufacturer home page: www.plustek.com
Manufacturer says: “Scanning Type Image Capture CMOS Optical Resolution Optical Resolution 1800 dpi Software Interpolation 3600 dpi x 3600 dpi Dynamic Range 2.0 Color Depth 24 bit/pixel Preview Speed Approx 8 sec (600dpi) Scan Speed Approx 8 sec (600dpi) Action Button Transparent & Negative Scan Scan Method Single Pass Protocols TWAIN Compliant Environment Requirement WEEE / ROHS Interface USB 2.0 ONLY Net Weight 308.5 g Dimensions (D x W x H) 104 x 155 x 100mm (4.05″x6.1″x3.93″)
Plustek OpticFilm 7500i SE
Class=7200dpi
Manually Loaded
Price Range $300-400
Manufacturer home page: www.plustek.com
Manufacturer says: “ Interface USB 2.0 Technology Color CCD image sensor Hardware Resolution 7200 x 7200 dpi Dynamic Range 3.5 Max. scanning area 36.8 x 25.4 mm (1.45 “x 1″) for negative film Preview Speed 11 sec (positive film), 11.38 sec (negative film) without calibration Scan Speed Approx.73 sec (3600 dpi), 332 sec (7200 dpi) for color slide Hardware Multi-Exposure on negative film Yes Multi-Sampling Yes Infrared Function Yes Color Depth 48 bit/pixel Scan Mode Single Pass Lamp Cold Cathode Dimensions (D x W x H) 272 x 120 x 119 mm / 4.73″x10.7″x4.7” (scanner only) Net Weight Approx. 1.6Kg / 3.5 lbs (scanner only) Film Holder Mounted slides, up to 4 slides Filmstrip, up to 6 frames Infrared BUILT-IN
Plustek OpticFilm 7600i SE
Class=7200dpi
Manually Loaded
Price Range $500-550
Manufacturer home page: www.plustek.com
Manufacturer says: “Interface USB 2.0 Technology Color CCD image sensor Hardware Resolution 7200 x 7200 dpi Dynamic Range 3.5 Max. scanning area 36.8 x 25.4 mm (1.45 “x 1″) for negative film Preview Speed 7.57 seconds for slide and 8.01 sec for negative film *without calibration time Scan Speed 3600dpi: Approx. 32.14 sec (multi-sampling ON) 7200dpi: Approx. 56.82 sec (multi-sampling ON) *under 24bit true color Hardware Multi-Exposure on negative film Yes Multi-Sampling Yes Infrared Function Yes Color Depth 48 bit/pixel Scan Mode Single Pass Lamp White LED Dimensions (D x W x H) 272 x 120 x 119 mm / 4.73″x10.7″x4.7” (scanner only) Net Weight Approx. 1.6Kg / 3.5 lbs (scanner only) Film Holder Mounted slides, up to 4 slides Filmstrip, up to 6 frames Infrared BUILT-IN
Plustek OpticFilm 7300
Class=7200dpi
Manually Loaded
Price Range $200
Manufacturer home page: www.plustek.com
Manufacturer says: “Interface USB 2.0 Technology Color CCD image sensor Hardware Resolution 7200 x 7200 dpi Dmax 3.5 Max. scanning area 36.8 x 25.4 mm (1.45 “x 1″) for Negative Preview Speed Negative Film: Approx 4.28 sec (Multi-Sampling ON / OFF) Postive Film: Aprrox 3 sec (Multi-Sampling ON / OFF) Scan Speed 3600 dpi: Approx. 24.22 sec (Multi-Sampling OFF) / 48.79 sec (Multi-Sampling ON) 7200 dpi: Approx. 97.29 sec (Multi-Sampling OFF) / 193.34 sec (Multi-Sampling ON) Hardware Multi-Exposure on negative film Yes Multi-Sampling Yes Color Depth 48 bit/pixel Scan Mode Single Pass Lamp Cold Cathode Illuminated Slide Viewer Size 38x38mm Dimensions (D x W x H) 272 x 120 x 119 mm / 4.73″x10.7″x4.7″ (scanner only) Net Weight Approx. 1.5 kg / 3.1 lb (scanner only) Film Holder Mounted slides, up to 4 slides Filmstrip, up to 6 frames Regulatory Certificates CE, FCC, UL/cUL, TUV, BSMI Accessories Padded Carry Bag Negative and Positive film holder Plustek Setup/Application CD-ROM SilverFast CD-ROM Quickguide USB cable 150cm Power Adaptor: Output 15V, 1.0A”
